Viofor JPS Family – Ref 1036
Viofor JPS Family – Ref 1037
The Family and Family + controllers needs magnetostimulation applicator for proper functioning. You can buy many applicators for one controller and use them interchangeably. Mat and pad applicators can be used simultaneously, increasing the effectiveness of therapy.
3S mat – Ref. 1040
3S mat – Ref. 1040
Mat intended for whole-body treatments – enables comfortable treatments in a lying position. Folded into three parts. Can be combined with other pad applicators.
6S mat – Ref. 1042
Mat intended for whole-body treatments – enables comfortable treatments in a lying position. Folded into six parts. Can be combined with other pad applicators.
2S mat – Ref. 1047
The 2 S mat allows the procedure to be performed in a sitting or lying position. Foldable – designed for frequent carrying. It does not connect with other applicators.
1S pad – Ref. 1045
For local use on small and medium areas – enables local treatments on all areas of the body, e.g. feet, back, knees.
2S pad – Ref. 1046
For local use on small and medium areas – allows local treatments for all areas of the body. It has twice the area of application than the 1S pillow.
Spot applicator – Ref. 1056
For local use on small and medium areas – enables local treatments on all areas of the body, e.g. feet, back, knees.
Elliptic applicator – Ref. 1054
Elliptical applicator used for small and medium joints and in dental cases. The application area is about 20 cm 2 (circle with a diameter of about 5 cm).
General information about the magnetic field applicators
In the applicators of Viofor JPS System the source of the magnetic field is formed in an electrical conductor coils. Med & Life produces heterogeneous field flat applicators and homogeneous field ring applicators. Induction of magnetic field generated by the coils is dependent on the dimensions of the coil, the number of turns and the electrical current flowing through the coil.
Flat applicators produce heterogeneous magnetic field, which means that induction measured at different locations on the surface of the applicator and under the applicator may have different values. With the distance from the surface of the applicator induction decreases, which limits the effective range of the magnetic field.
Increasing the “saturation”magnetic field can be achieved by the simulataneous use of two flat applicators.
Homogeneous field applicators, such as ring applicators are made of coils properly completed and placed in space to each other. They produce homogeneous field in the large space inside the applicator. This means that the homogeneity of the field has the same value of the induction, the same direction and sense in a given instant of time. The location of the body in the uniformity is ensured by the desing of applicators. A characteristic feature of the applicator is the generation of magnetic field with its lines of force parallel to the axis of the applicator and the patient`s body (in the flat applicators lines pass perpendicularly trough the body).
Choice of applicators
The values of magnetic field induction is related to the distance from applicator surface. It could be said that the larger applicator, the deeper magnetic field insertion.
When you need deep insertion, you should
- choose large area applicator
- use two flat applicators connected by adaptor
- or use a ring applicator
Applicator combining (usage of two applicators)
The aim of the combination is to increase the efficiency of the therapy.
General principle for applicator combining
- combining applicators applies to selected magnetic stimulation applicator
- connection can be done only with the original adaptor changes the parameters of treatment
- for the optimum effect of the combining the applicators should be positioned parallel to each other and the surfaces contact with the body should have different colours
Indications Pulsed magnetic Field Stimulation
– spondyliosis of the spine and osteoarticular system of the upper and lower limbs
– rheumatoid arthritis (RA)
– ankylosing spondylitis
– joint injuries.
2. Soft tissue:
– extra articular rheumatism ( so-called fibromyalgia)
– soft tissue injuries
– conditions after injury(interruption)to the continuity of tissue (including post-surgical).
1. bone structure
– osteoporosis, particularly post-menopausal (concerns prophylaxis as well as therapy)
– conditions after bone crack and fracture
– conditions after operations on bone structure
2. soft tissues:
– conditions after injury with or without damage to skin continuity
Improving peripheral circulation activity
1. improper local (topical) blood flow in the limbs:
– in diabetic angiopathy
– in atherosclerotic angiopathy
– in crural ulceration
2. accelerated absorption of haematomas
– conditions after apoplexy
– degenerative diseases of the nervous system, accompanied by spasticity
– sleep disorders
– stress, particularly after long-term psychic/mental tension
– concentration disorders
Pulsed Magnetic Field Stimulation in dentistry-regenerative and analgesic activity.
-periapical lesions – conservative treatment of periapical tissue inflamations
-nerve damage,complications after anaestesia
– complications after dental surgery
– complication after endodonic treatment
– dry socket as orthodontic treatment adjuvant
Contraindications to Pulsed magnetic Field Stimulation
– neoplastic disease
– bleeding from the alimentary tract
– sever infections of a viral, bacterial
and mycotic origin
– electronic implants
– conditions after organ transplants
Side effects Pulsed Magnetic Stimulation, adverse effect
Until now, no serious side effects of magnetic field simulation have been reported. The following effects might occur temporarily:
– a tingling, numbing and warmth sensation, may occur particulary in the first three or four days of exposure; this applies in particular to post-traumatic areas of the osteoarticular system,
– sleep disorders are observed only in aprox. 3% of elderly patients,
– irritation and/or concentration disorders, temporary intensification of pain are chiefly experienced by women during menopause as well as people with increased tension of the neurovegetative system; these symptoms are usually observed in the first days following exposure.Such symptoms affect approx. 4% of women and 1% of men.
– A temporary intensification of pain usually occurs in the first period of exposure and affect people with significant degenerative changes in the osteoarticular system.
Viofor JPS generates variable magnetic fields, which cause changes in the organism similar to those caused by physical activity (physical strain, physical activity); i.e. they support biological regeneration. Both mental and physical regeneration is tightly connected with physical exercise. Variable magnetic field plays a similar beneficial role.
Magnetostimulation stimulates in the organism electromotor forces of such properties, which enable homeostasis, and in case of its disturbance stimulate return to a normal state.
Biological effect of variable magnetic field generated by Viofor JPS is the result of:
- electrodymanic effect on ion currents in the body
- magnetomechanic effect of the magnetic field on particles with uncompensated magnetic spin
- ionic cyclotron resonance of cations and anions in the body fluids
Body fluids i.e. blood, the lymph and intercellular fluid constitute so-called second mode conductors of the ionic character of electrical conductivity. The essence of the Viofor JPS system is the optimal choice of two different electrical (and thus magnetic) signals as well as their mutual combination, in order to achieve the aforementioned three fundamental mechanisms of variable magnetic field absorption by the living matter.
ELF (Extremely Low Frequency) electromagnetic radiation may affect an organism in various ways.
In magnetostimulation, due to extremely low value of magnetic induction, the most important are bio-electric, biochemical and bioenergetic effect
- The bioelectric effect causes normalization in the potential of the cell membrane. In pathological cases, the potential drops due to penetration through the cell membrane to the cell interior of positive ions, e.g. Na+. In order to reverse the process, the cell needs energy, which can be obtained from ATP hydrolysis. .
- The biochemical effect is based on an increased enzymatic activity as well as reduced processes related with ATP. .
- The bioenergetic effect is a factor that stimulates the nutrition and growth of cells and regulates intercellular processes leading to regeneration of the organism..
Main effects of biological magnetostimulation mechanisms:
Analgesic action takes place mainly due to an increase in the secretion of endogenous opiates from the ß-endorphin group, a substance responsible for the increase in pain threshold. The effect of analgesic action occurs not only during exposure to magnetic fields, but is also observed after exposure is discontinued. This determines the biological hysteresis of magnetic field effect. Precisely such a mechanism of analgesic action on the internal opioid system confirms an antagonist of opiates blocking this effect (Naloxone).
An intensification of the processes of oxygen utilization and tissue respiration as a result of intensified diffusion as well as oxygen capture by hemoglobin and cytochrome chiefly determines the basis of regenerative effects. The increased capture of oxygen is associated with a stimulation of the processes of tissue respiration, DNA synthesis and acceleration of the mitotic cycle. As a result, magnetic fields treat trophic lesions of the shank, accelerate the healing of ulcerous niches, improve the cellular metabolism of the central nervous system and accelerate regeneration of damaged peripheral nerves.
Very weak currents generated due to interaction on piezoelectric substances e.g. collagen, stimulate the activity of osteoblasts. It is aided by intensification of vasodilatatory effects. It has also been observed that a magnetic field inhibits demineralization processes of the bones and, at the same time, increases their mineralization – which is evaluated by densitometry.
Anti-inflammatory action is connected with the stimulation of formation of c-AMP and E prostaglandin. Prostaglandin influences the accumulation of c-AMP, which decreases the secretion of inflammation mediators from neutrophiles, basophiles, mastocytes and lymphocytes.
Relaxing and antispastic effect on the nervous system
In case of the nervous system, magnetic fields also improve the interneuron conductivity and modulation of neuron activity as well as the pineal gland’s twenty-four hour rhythms of melatonin secretion, which is called” the scavenger of free radicals” responsible, among others, for the aging process. The pulsating magnetic fields generated by the Viofor JPS clearly modify the amplitude value of alpha and theta wave rhythms in proper directions, characteristic for the physiological state of relaxation – objectively measurable and indicated by value of the demobilization of the autonomous system. The results of psychophysical testing, as a part of psychotherapy of emotionally immature people point to Viofortherapy as a method of choice for these people. What is more, it is a non-invasive method applied equally in medicine as in psychology.
Viofor JPS system magnetostimulation has a documented analgesic, anti-inflammatory, antispastic, regenerative effect; it also improves blood circulation. Magnetostimulation is particularly recommended to treat pain of various origin, motor system diseases or neurological diseases. It is very effective in posttraumatic, post-burn and neurological rehabilitation.
In many cases it allows reducing the drug intake, painkillers in particular
Treatment time: default settings 8, 10 or 12 minutes
Treatment can be provided to patients in any position (lying or sitting). It does not need any special preparations. The application is automatic and there is no need to involve third parties.
Each treatment session includes the following parameters: Program (P), application mode (M) and intensity / level (I).
There are three groups of indication: prophylaxis, medical treatment and rehabilitation..
Prophylactic treatments should be applied two times a day. They provide comfortable and relaxing sessions. Two applicators can be used for prophylactic treatment: large flat applicator – mat and cot
Treatment and rehabilitation
Application parameters can be set according to the disease, patient’s age and general condition as well as treatment length. A wide choice of accessories allows general and local application. Large applicators (mat and cot) are used for the whole body treatment. Local applicators are used for selected body part treatment. They provide non-invasive and pain free treatment that patients can apply on their own.
For children, parameters are set according to age groups.
Kinds of Therapies
- Pulsed Magnetic Field Stimulation (PMF Simulation) in the JPS System
For Pulsed Magnetic Field Stimulation purposes, Viofor JPS System generates pulsed electromagnetic field using complex shape pulses with multi-peak structure, resulting in multiple signals across a frequency spectrum.
The shape of the signal:
the two types of the saw-like shape of impulse.
The frequencies are present by the manufacturer.
The Magnetic signal consist of:
- the basic frequencies range: 180-195 Hz
- the frequencies of the impulse packets range: 12,5-29 Hz,
- the packet groups range: 2,8-7,6 Hz
- the series range:0,08-0,3 Hz
Magnetic induction depends on the selected applicator as well as functional setting.
The average magnetic induction values are far lower than those used in Pulsed Magnetic Field Therapy, for most Viofor JPS applicators up to 100 µT.
Duration of the treatment is present by the manufacturer when the desired functional setting is selected. Total duration of the treatment last 8 minutes, 10 minutes or 12 minutes.
- Pulsed Magnetic Field Therapy
Frequency: 5-40 Hz, in 5 Hz step
Magnetic induction: 0,19 – 6,00 µT (set by the intensity level in the range of 0,5 – 12)
Duration of the treatment: 10- 30 min, in 5 min step
The shape of the signal: sinusoidal, triangular, rectangular
- LED Therapy
LED Therapy is a form of phototherapy which entails the use of energy of unpolarized and incoherent light in the visible red and infrared light generated by high-energy LEDs.
Maximum radiation power: from 400 m W to 6800 mW, depends on the applicator.
Average radiation power: from 1mW, or 10% maximum radiation power to full maximum radiation power, depends on the control unit.
Radiation frequency:181.8 Hz (optical radiation is emitted at a constant frequency of 181.8 Hz, which is one of the main frequencies of Pulsed Magnetic Field Stimulation in the JPS System).
Duration of the treatment:1-30 min.
- Pulsed Magnetic Field LED Therapy
Pulsed Magnetic Field LED Therapy means using of Viofor JPS Pulsed Magnetic Field Stimulation and LED Therapy at the same time.
Pulsed magnetic Field LED Therapy in Viofor JPS System uses red and infrared optical radiation with parameters like in low-energy laser therapy.
Synchronous Pulsed Magnetic Field LED Therapy
– impulses of magnetic field and LED radiation are synchronized.
Asynchronous Pulsed Magnetic Field LED Therapy
– impulses of magnetic field and LED radiation are not synchronized.
Maximum radiation power: from 400 mW to 6800 mW, Depends on the selected applicator.
Average radiation power: depending on the selected control unit from a hew mW (Clinic,Delux) or from 10% maximum radiation power to maximum radiation power (Light,MagneticLight)
Radiation frequency:181.8 Hz (optical radiation is emitted at a constant frequency of 181.8 Hz, wich is one of the main frequencies of pulsed magnetic field stimulation in the JPS System.
Duration of the treatment: 8 min, 10 min, 12 min or x2,x 3, depends on selected control unit.
The shape of the signal: Pulsed magnetic Field Stimulation with the two types of the saw-like shape of impulse.
- Laser Therapy
Laser Therapy is a kind of light therapy which uses energy of coherent and monochromatic laser radiation in red and infrared radiation range, generated by semiconductor laser.
Dose (density) of radiation energy:1-99 J/cm2
Radiation frequency: 181.8 Hz (optical radiation is emitted at a caostant frequency of 181.8 Hz, which is one of the main frequencies of pulsed magnetic field stimulation in the JPS System).
Maximum radiation power: 30 mW for red radiation and 300 mW for infrared radiation.
Average radiation power: from 1mW up to full maximum radiation power, deprnds on the applicator ( continuous mode).
Duration of the treatment: 10-30 min in 10 sec step.
- Pulsed Magnetic Field Laser Therapy
Pulsed Magnetic Field Laser Therapy usage of Pulsed Magnetic Field Stimulation and Laser Therapy in the same time.
Pulsed Magnetic Field Laser Therapy in Viofor JPS System uses red and infrared laser radiation with low energy parameters.
Impulses of pulsed magnetic field and laser radiation are not synchronized.
Dose (denisty)of radiation energy: 1-99 J/cm2.
Radiation frequency: 181.8 Hz (optical radiation is emited at a constant frequency of 181.8 Hz, which is one of the main frequency of Pulsed Magnetic Field Stimulation in the JPS System).
Maximum radiation power:30 mW for red radiation and 300 mW for infrared radiation.
Average radiation power: from 1 mW, up to full maximum radiation radiation power, depends on the applicator (continous mode).
The shape of the signal: Pulsed Magnetic Field Stimulation with the two types of the saw-like shape of impulse.
Duration of the treatment:
- separately sets for laser radiation – from 1 min to 10 min in 10 sec step
- separately sets for pulsed magnetic field 8 min, 10 min, 12 min.
- PhotoDynamic Therapy (PDT)
The basis of PDT is the joint action of the photosensitizer, oxygen and light of an appropriate wavelength that is selectively absorbed by the photosensitizer.The result is a photodynamic action which enables the selective destruction of pathological tissue or the inferected area.
S PDT Viofor System allows completion of the procedure of the PhotoDynamic Therapy (PDT) in providing appropriate radiation dose for the treatment of a change qualified to the PhotoDynamic Therapy.
The LED Therapy Spot Applicator can be used to PDT (PhotoDynamic Therapy) ensuring a correct dosage of light energy for photosensitizers with a wavelength of 632 nm.
The PDT terapist decides what indications and energy dose and which photosensitizer should be used when carrying out the procedure.
The equipment can be used for PDT that does not involve contact with the skin: the vulva,the male external genitals and oral mucosa.In recent years there has been a discernible rise in the use of PDT for the treatment of inflamatory states e.g.: acne vulgaris, curural ulcers, diabetic foot, syndrome nad inflammation of the external genitals.
The equipmant meets the technical criteria necessary for treatments accessible for non-endoscopic and non-contact application.
